Helioseismic & Magnetic Imager Solar Dynamics Observatory The HMI Team: Stanford University, Lockheed-Martin Solar and Astrophysics Laboratory, High Altitude Observatory, and 22 Co-Investigator Institutions

HMI Major Science Goals

The primary goal of the Helioseismic and Magnetic Imager (HMI) investigation is to study the origin of solar variability and to characterize and understand the Sun’s interior and the various components of magnetic activity. The HMI investigation is based on measurements obtained with the HMI instrument, one of the three instruments that make up the Solar Dynamics Observatory (SDO) mission. HMI makes measurements of the motion of the solar photosphere to study solar oscillations and measurements of the polarization in a specific spectral line to study all three components of the photospheric magnetic field. HMI produces data to determine the interior sources and mechanisms of solar variability and how the physical processes inside the Sun are related to surface magnetic field and activity. It also produces data to enable estimates of the coronal magnetic field for studies of variability in the extended solar atmosphere, which is where the Earth is. Solar variability that affects the Earth “space weather.” HMI observations will help establish the relationships between internal dynamics and magnetic activity. In turn this will lead to better understanding of solar variability and its effects. This will lead to reliable predictive capability, one of the key elements of the Living With a Star (LWS) program. HMI investigation goals are to observe and understand these interlinked processes of magnetic activity and internal dynamics including:

• Convection-zone dynamics and the solar dynamo;

• Origin and evolution of sunspots, active regions and complexes of activity;

• Sources and drivers of solar activity and disturbances;

• Links between the internal processes and dynamics of the corona & heliosphere;

• Precursors of solar disturbances for space-weather forecasts.

HMI Implementation

The HMI instrument design and observing strategy are based on the highly successful MDI instrument, with several important improvements. HMI will observe the full solar disk in the Fe I absorption line at 6173A with a resolution of 1 arc-second. HMI consists of a refracting telescope, a polarization selector, an image stabilization system, a narrow band tunable filter and two 4096? pixel CCD cameras with mechanical shutters and control electronics. The continuous data rate is 55Mbits/s.

Images are made in a sequence of tuning and polarizations at a 4-second cadence for each camera. One camera is dedicated to a 45s Doppler and line-of-sight field sequence while the other to a 90s vector field sequence. All of the images are downlinked for processing at the HMI/AIA Joint Science Operations Center at Stanford University.

HMI Science: Solar Interior Dynamics and Photospheric Magnetic Fields

The downward propagating waves are refracted upward by the temperature gradient and the upward propagating waves are reflected inward by the drop in density at the surface. The travel times of these waves depend on the temperature, composition, motion, and magnetic fields in the interior. The visible surface moves when the waves are reflected. HMI measures this motion enabling the wave frequency, phase, and amplitude to be measured. Analysis of travel times over a multitude of interior paths enables inference of internal conditions. Solar Magnetic Fields: The Sun is permeated by magnetic fields on multiple scales from “flux tubes” smaller than 70km to 30,000km sunspots to the Sun-covering magnetic network. It is the dynamically changing magnetic fields that is the source of nearly all solar variability that effects the Earth and human technological systems. HMI will provide the first full-disk continuous observations of solar magnetic fields in all orientations. Prior measurements (e.g. MDI) measured only the component of the field along the line of sight to the observer. The new measurements should improve our understanding of the 3-D structure of the evolving field. We can only measure the fields in the layer of the atmosphere where most all of the light originates (photosphere) and we can then compute estimates of the field in the upper atmosphere where AIA observes the effects of the fields.

Examples of science data products from SOHO/MDI. Improved versions of these can be made with HMI observations: A. Sound speed variations relative to a standard solar model. B. Solar cycle variations in the sub-photospheric rotation rate. C. Solar meridional circulation and differential rotation. D. Sunspots and plage contribute to solar irradiance variation. E. MHD model of the magnetic structure of the corona. F. Synoptic map of the subsurface flows at a depth of 7 Mm. G. SOHO/EIT image and magnetic field lines computed from the photospheric field. H. Active regions on the far side of the sun detected with helioseismology. I. Vector field image showing the magnetic connectivity in sunspots. J. Sound speed variations and flows in an emerging active region.

How HMI Works: HMI measures a long sequence of Dopplergrams (maps of solar surface velocity) and magnetograms (maps of magnetic field at the Sun’s visible surface, the photosphere.) Each map of motion or magnetic field is computed on the ground from a set of 12 images of the Sun, each obtained with a different combination of wavelength tuning and polarization direction. The wavelength tuning compared to the chosen solar spectral absorption line is shown in this figure. The black line at the top shows the solar iron spectral line profile. The. colored lines show the HMI filter transmission profiles at 7.6 nm tuning spacing.

The black dashed line is the profile used for the continuum filtergram. A picture is made for each tuning and the results are used to compute velocity and magnetic field strength at each pixel. The polarization selector needed for magnetic field measurements is a set of waveplates that can be rotated to different angles for detection of different polarization parameters (called Stokes I,Q,U,V) The wavelength selection and tuning is accomplished with a set of successively narrower bandpass filters. These are the front window, blocking filter, a five element Lyot filter, and two Michelson interferometers. The last three filter stages can be tuned by rotating retarder waveplates. The combination results in a 7.6nm bandpass that can be tuned over 68nm and is centered on the 617.3nm solar line. (1nm = 10Å)

HMI Specifications
Central wavelength	6173.3 Å ± 0.1 Å (Fe I line)
Filter bandwidth	76 mÅ ± 10 mÅ fwhm
Filter tuning range	680 mÅ ± 68 mÅ
Central wavelength drift	< 10 mÅ during any 1 hour period
Field of view	> 2000 arc-seconds
Angular resolution	better than 1.5 arc-seconds
Detector resolution	0.50 ± 0.01 arc-second / pixel
Focus adjustment range	± 4 depths of focus
Pointing jitter reduction factor	> 40 db with servo bandwidth > 30 Hz
Image stabilization offset range	> ± 14 arc-seconds in pitch and yaw
Pointing adjustment range	> ± 200 arc-seconds in pitch and yaw
Dopplergram cadence	< 50 seconds
Camera Image cadence	< 4 seconds
Timing	< 1 µs stability, < 100 ms absolute
Science telemetry allocation	< 55 Mbits/s
Instrument design lifetime	> 5.3 years

Doppler Velocity
Cadence	45 s
Precision	13 m/s
Zero point accuracy	0.05 m/s
Dynamic range	±6.5 km/s
Line-of-Sight Magnetic Flux
Cadence	45 s
Precision	10 G
Zero point accuracy	0.05 G
Dynamic range	± 4 kG
Continuum Intensity
Cadence	45 s
Precision	0.3%
Accuracy pixel to pixel	0.1%
Vector Magnetic Field
Cadence	90 s
Precision
Polarization	0.22%
Sunspots (1kG<|B|<4kG) *
|B|	18G
Azimuth	0.6 °
Inclination	1.4 °
Quiet Sun (0.1kG<|B|<2kG) *
|B|	220 G
Total flux density	35 G
Azimuth	15°
Inclination	18°

History / Background / Prior missions

The need for an instrument like HMI was recognized in 1996 with the conceptual design developed in 1998. The SDO mission definition study in 2001 clarified the requirements, with real work on HMI beginning after a competitive selection process in 2002. The Helioseismic and Magnetic Imager is a new and improved version of the Michelson Doppler Imager (MDI) instrument on the Solar and Heliospheric Observatory (SOHO). SOHO is a joint project of the European Space Agency and NASA. MDI was developed starting in 1988 by the same collaboration between Stanford and Lockheed teams that developed HMI. SOHO was launched in December 1995. SOHO/MDI is presently still operating well and has completed helioseismic and magnetic field observation of the Sun for all of solar cycle 23 and the beginning of cycle 24. HMI will continue these important measurements from space into the next solar cycle. We hope and anticipate that SDO/HMI will enable deeper understanding of solar processes during most of solar cycle 24.

Links

SDO web link: http://sdo.gsfc.nasa.gov
HMI web link: http://hmi.stanford.edu
HMI/AIA JSOC data center web link: http://jsoc.stanford.edu

HMI Team

HEPL, Stanford U. **Phil Scherrer *Richard Bogart *Rock Bush *Tom Duvall, Jr. *J.Todd Hoeksema *Alexander Kosovichev *Jesper Schou *XuePu Zhao Jim Aloise Art Amezcua Taeil Bai John Beck Kelly Beck Elena Benevolenskaya Sudeepto Chakraborty Keh-Cheng Chu Millie Chethik Nancy Christensen Carl Cimilluca Sebastien Couvidat Priya Desai Romeo Durscher Christina Green Sarah Gregory Thomas Hartlep Keiji Hayashi Tim Huynh Stathis Ilonidis Kevin Kempter Irina Kitiashvili Anna Kosovicheva Rasmus Larsen Tim Larson Yang Liu Leyan Lo James Mason Rakesh Nigam Konstantin Parchevsky Bala Poduval M, Christina Rabello- Soares Brian Roberts Kim Ross	Deborah Scherrer Jeneen Sommers Jennifer Spencer Margie Stehle Xudong Sun Hao Thai Karen Tian Richard Wachter Jeff Wade Junwei Zhao HEPL Staff LMSAL *Alan Title *Karel Schrijver *TedTarbell Dave Akin Brett Allard Ron Baraze M. Baziuk Tom Berger Paul Boerner E. Bogle Bob Caravalho Brock Carpenter C. Cheung Roger Chevalier K. Chulick Tom Cruz Jerry Drake Dexter Duncan Jay Dusenbury Chris Edwards Janet Embrich Cliff Evans Peter Feher Barbara Fischer Chuck Fischer Sam Freeland Frank Friedlander Glen Gradwohl Hank Hacook Gary Heyman Bob Honeycutt Elizabeth Hui Bruce Imai Jerry Janecka Romona Jimenez Dwana Kacensky Pete Kacensky	Claude Kam Karen Kao Noah Katz Dave Kirkpatrick Gary Kushner Michael Levay Russ Lindgren Gary Linford Andrea Lynch Dnyanesh Mathur Ed McFeaters John Miles Keith Mitchell Sarah Mitchell Ruth Mix Margaret Morgan Rose Navarro Tom Nichols Tracey Niles Jackie Pokorny Rick Rairden Roger Rehse J.-P. Riley Lomita Rubio David Schiff Isella Scott Cherl Seeley Ralph Sequin Dick Shine Lawrence Shing Araya Silpikul Larry Springer Bob Stern Louie Tavarez R. Timmons Edgar Thomas Darrell Torgerson Shan Varaitch Angel Vargas Dale Wolf Jake Wolfson Ross Yamamoto Carl Yanari Kent Zickuhr HAO *Steve Tomczyk Juan Borrero Santiago Gregory L. Card	Anthony Darnell Rebecca C. Elliott David Elmore Jonathan Graham Aimee Norton Bruce Lites Arturo Lopez Ariste Matthias Rempel Hector Socas-Navarro JPL Michael Turman U. of Colorado *Juri Toomre Benjamin Brown Gwen Dickenson Nicholas Fetherstone Deborah Haber Bradley Hindman Swati Routh Regner Trampedach NASA Ames *Nagi Mansour *Alan Wray NJIT, BBSO *Phil Goode Vasyl Yurchyshyn NWRA/CoRA *Doug Braun *Tom Metcalf† *Charlie Lindsey Graham Barnes Aaron Birch Ashley Crouch K. D. Leka Orion Poplawski Martin Woodard NSO *Frank Hill *Rachel Howe Walter Allen Olga Burtseva Irene Gonzalez-Hernandez Kiran Jain Shukur Kholikov Rudi Komm	Igor Suarez-Sola Sushanta Tripathy Predictive Science Inc. *Jon Linker Michael Choy Zoran Mickic Pete Riley Timofey Titov Janvier Wijaya SAO *Sylvain Korzennik Alisdair Davey UCLA *Roger Ulrich U. of Hawaii *Jeff Kuhn Marcelo Emilio Isabelle Scholl UMCP *Judit Pap USC *Ed J. Rhodes, Jr. Shawn Irish Johann Reiter Anthony Spinella Yale University *Sarbani Basu Charles Baldner International Aarhus University,DK *Joergen Christensen-Dalsgaard Cambridge, UK *Douglas Gough ESA *Bernhard Fleck IIAP, IN Dipankar Banerjee Siraj Hasan S. Paul Rajaguru	MPS, DE *Sami Solanki Raymond Burston Laurent Gizon Shravan Hanasoge Yacine Saidi MSSL, UK *Len Culhane Elizabeth Auden NAOJ, JP *Takashi Sekii Kaori Nagashima RAL, UK *Richard Harrison Sheffield Univ. UK *Mike Thompson Univ. Tokyo, JP *Hiromoto Shibahashi Industrial e2v - CCDs Gary Auker Rob Wilson RAL - Cameras Nick Waltham Light Machinery - Michelson interferometers John Hunter Ian Miller Andover Corporation & Zygo Corporation - Filters John Cotton H. Magnetics - motors Ralph Horber
*Co-Investigator, **Principal Investigator, HEPL: W.W. Hansen Experimental Physics Laboratory; LMSAL: Lockheed-Martin Solar and Astrophysics Laboratory; HAO: High Altitude Observatory; JPL: Jet Propulsion Laboratory; NJIT,BBSO: New Jersey Institute of Technology, Big Bear Solar Observatory; CoRA: Colorado Research Associates; NSO: National Solar Observatory; SAO: Smithsonian Astrophysical Observatory; UMCP: University of Maryland College Park; ESA: European Space Agency; IIAP: Indian Institute of Astrophysics; MPS: Max Planck Institute for Solar System Research; MSSL: Mullard Space Science Laboratory; NAOJ: National Astrophysical Observatory of Japan; RAL: Rutherford Appleton Laboratory. †Deceased.
